| Main Processor |
Embedded processor |
| Button Type |
Touch button |
| Network Protocol |
UDP; TCP; IPV4; RTSP; SIP; P2P; RTP |
| OSDP Protocol |
Yes |
| Interoperability |
CGI; ONVIF |
| SDK and API |
Yes |
| Product Type |
Standalone |
| Display Screen |
4.3 “LCD |
| Screen Type |
Capacitive Touchscreen |
| Screen Resolution |
272 (H) X 480 (V) |
| Camera |
2-MP CMOS HD dual lens camera |
| WDR |
DWDR |
| Light Compensation |
Auto IR |
| Voice Prompt |
Yes |
| Buzzer |
Yes |
| Casing Material |
PC +GF |
| Unlock Mode |
Card, remote, password, QR code, Face and Combination unlock |
| Card Type |
Mifare/Proximity |
| Period List |
128 periods |
| Holiday Period |
128 periods |
| Network Update |
Yes |
| First User Unlock |
Yes |
| Remote Verification |
Yes |
| Restricted List/Trusted List |
Yes |
| Peripheral Card Reader |
1 x RS-485 card reader, 1 x wiegand card reader |
| Multi User Authentication |
Yes |
| Real Time Monitoring |
Yes |
| Multi Factor Authentication |
Yes |
| Capture Function |
Yes |
| Web Configuration |
Yes |
| Auto Registration |
Paper; Electronic |
| Card Reading Distance |
0 cm - 3cm ( 0” - 118”) |
| Face Recognition Height Range |
1.1m - 2.0m ( 3.61 ft - 6.56ft) |
| Face Recognition Distance |
0.3m - 1.5m ( 0.98 ft - 4.92ft) |
| Face Recognition Accuracy |
99.9% |
| Face Recognition Time |
0.2 s |
| User (card) type |
Normal user; VIP users; patrol users; guest users; |
| FUser (card) type |
blocklist users; other users; custom users 1; custom users 2 |
| User Capacity |
6,000 |
| Face Image Capacity |
6,000 |
| Card Capacity |
10,000 |
| Password Capacity |
6,000 |
| Record Capacity |
3,00,000 |
| RS-485 |
1 |
| Wiegand |
1 |
| USB |
1 |
| Network Port |
1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| Alarm Linkage |
Yes |
| Alarm Input |
1 |
| Alarm Output |
1 |
| Exit Button |
1 |
| Lock Control |
1 |
| Door Status Detection |
1 |
| Anti-pass Back |
Yes |
| Tamper Alarm |
Yes |
| Duress Alarm |
Yes |
| Door Sensor Timeout |
Yes |
| Intrusion |
Yes |
| Illegal Card Exceeding Threshold |
Yes |
| Power Adapter |
Included |
| Power Supply |
12 VDC, 1.5 A |
| Protection |
IP 65 |
| Power Consumption |
<= 12W |
| Product Dimensions |
180.1mm x 90.1mm x 27mm (7.09” x 3.55” x 1.06”) L X W X H |
| Packing Dimensions |
590 mm x 432 mm x 302mm (23.23” x17.01” x 11.89”) |
| Operating Temperature |
-30 c to +60c (-22 F to +140 F) |
| Operating Humidity |
0% -90% (RH), non condensing |
| Operating Altitude |
0 — 1,300m (0 ft -4265.09 ft) |
| Operating Environment |
Outdoor ; Indoor |
| Gross Weight |
0.70 kg ( 1.54 lb) |
| Accessory |
Wall mount br acket (included) |
| Installation |
Turnstile mount; 86 case mount; wall mount; surface mount |
